| X axis travel | mm (in) | 2000 (78.7) |
| Y axis travel | mm (in) | 1800(70.8) |
| Z axis travel | mm (in) | 1300(51.1) |
| W axis travel | mm (in) | 500(19.6) | 700(27.5) |
| From spindle nose to the centerline of table | mm (in) | 200(7.8)~2000(78.7) | 0~2000(78.7) |
| Table dimension (X direction) | mm (in) | 1440 (56.7) |
| Table dimension (Y direction) | mm (in) | 1600 (63) |
| The samllest split angle of table | degree | 0.001 |
| Table loading | kg (lb) | 8000 (17637) |
| Spindle motor power | kW (HP) | 22/26 (30/35) |
| Spindle speed | rpm | 3500 | 2500 |
| Spindle taper | | BT#50 (ISO 50) |
| Rapid feedrate - X axis | mm(in)/min | 15000 (590.6) |
| Rapid feedrate - Y axis | mm(in)/min | 12000 (472.4) |
| Rapid feedrate - Z axis | mm(in)/min | 15000 (590.6) |
| Rapid feedrate - W axis | mm(in)/min | 5000 (196.9) |
| Rapid feedrate - B axis | round/min | 0.5 |
| Cutting federate | mm(in)/min | 12000(472.4) |
| Capacity of tool magazine | pcs | 40 |
| Max tool diameter / Adjacent pocket empty | mm (in) | 125/250 (4.9/9.8) |
| Max. tool length | mm (in) | 400(15.7) |
| Max. tool weight | kg (lb) | 25(55) |
| Positioning accuracy (JIS 6338) | mm (in) | ±0.010 (±0.0009/full travel) |
| Positioning accuarcy of X, Y axis (VDI/DGQ 3441) | mm (in) | P≦0.016 (0.0006)/ full length |
| Positioning accuracy - Z axis (VDI/DGQ 3441) | mm (in) | P≦0.025(0.000984)/full travel |
| Repeatibility accuracy (JIS 6338) | mm (in) | ±0.05(0.001969) |
| Repeatibility accuracy (VDI/DGQ 3441) | mm (in) | Ps≦0.012 (Ps≦0.0005) |
| Repeatibility accuracy-Z axis (VDI/DGQ 3441) | mm (in) | Ps≦0.018(0.000709) |
| Length of the machine | mm (in) | 6325(249) |
| Width of the machine | mm (in) | 6292(247.7) |
| Height of the machine | mm (in) | 4128(162.5) | 4165(163.9) |
| Weight of the machine | kg (lb) | 31000(68343) | 32500(71650) |
